Smart
Smartbar features
Voice control, fingerprint unlock, LED dot-matrix display
Connectivity
Connect Service with 4G, Bluetooth & WiFi
IoT sensors
Accelerometer, gyroscope, torque
App
iOS & Android
Power
Motor
Carbon 1: 36 V 250 W (rated), 35 N⋅m
Carbon 1s: 36 V 350 W (rated), 45 N⋅m
Speed modes
Pedal, Eco, Comfort, Sport, Turbo
Top speed (assisted)
Carbon 1: 20mph
Carbon 1s: 25mph
Range
25~60 miles
Removable battery
9.8 Ah 352.8 Wh Samsung Li-ion, 2.5-hr quick charge, certified to UL-2271
General
Weight
Carbon 1: 33 lbs.
Carbon ls: 35 lbs.
Payload Capacity
Max. 240 lbs.
Sizes
Small, Medium, Large (see Size Guide)
Body material
Carbon fiber (frame, fork, handlebar, seatpost)
Brakes
Front & rear dual-piston hydraulic disc
Tires
Kenda Kwest 700x35C (35 mm / 1.4”) (30~45 mm compatible)
Integrated lights
StVZO headlight; Advanced Rear Early-indication System (ARES)
Wheels
700C (ISO 622 mm BSD), inner rim 19 mm
Gearing
Carbon 1: Gates Carbon Drive™ CDN™ belt (up to 19,000 miles)
Carbon 1s: Shimano 7-Speed Rear Drivetrain
What’s in the Box
Urtopia Carbon one
Front Wheel, Frame, Seatpost, saddle, Pedals
Removable battery
Battery, Charger, Battery key
Frame (accessory) bag
4mm Allen wrench, 15mm combination wrench, front-wheel quick-release device
